MC07XS3200EK
Part Number: MC07XS3200EK
Manufacturer: Freescale
Package: 32-BSSOP (0.295", 7.50mm Width) Exposed Pad
Quantity: 42
Description: IC SWITCH DUAL 32SOIC SPDL07
Request Quantity:
PDF:

Product Information:


Standard Package:42
Packaging:Tube
Switch Type:General Purpose
Number of Outputs:2
Ratio - Input:Output:1:2
Output Configuration:High Side
Output Type:N-Channel
Interface:SPI
Voltage - Load:6 V ~ 20 V
Voltage - Supply (Vcc/Vdd):3 V ~ 5.5 V
Current - Output (Max):26A
Rds On (Typ):7 mOhm
Input Type:-
Features:Internal PWM, Slew Rate Controlled, Watchdog Timer
Fault Protection:Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature:-40°C ~ 150°C (TJ)
Package / Case:32-BSSOP (0.295", 7.50mm Width) Exposed Pad
